- MATERIALS:
- Flange & Support Arm — 18-8, type-304, 22-gauge (0.8mm) stainless steel. Concealed, 18-gauge (1.2mm) stainless steel
mounting bracket. All-welded construction. Secured to wall plate with a stainless steel setscrew - Concealed Wall Plate — 18-8, type-304, 19-gauge (1.0mm) stainless steel.
- Cap — 18-8, type-304, 14-gauge (2.0mm) stainless steel. Welded to the support arm.
- Specify Model Required:
- Model B-7672 Bright polished stainless steel
- Model B-76727 Satin-finish stainless steel
